SKID STEER LOADER T460
SKID STEER LOADER T460
Product Detail
PRODUCT APPLICATION
Itis mainly used in situations where the working site is small, the ground is uneven, and the work content changes frequently. Itis suitablefor infrastructure construction, industrial applications, dock loading and unloading., urban streets, residential buildings, barns, livestocksheds, airport runways, etc. It can also be used as auxiliary equipment for large-scale engineering construction machinery.
FEATURE
Compact and flexible, convenient for small terrain and narrow space operations.
Simple and convenient operation, convenient transportation.
Use thicker high-quality steel, apply plastic molding process, prevent rust and anti-corrosion.
The 360-degree body rotates freely, and the smart body facilitates outdoor work.
Specifications
Basic performance parameters
Operating weight 1120kg
Bucket capacity 0.1m²
Climbing ability 25°
Maximum breakout force 4.5KN
Rated load 300kg
Maximum load 400kg
Travel speed 0-5km/h
Vehicle width 1040mm
Rated pressure 16Mpa
Bucket width 1050mm
Max loading height 1720mm
Max dumping height 1401mm
Max operating height 2110mm
Height to bucket pin 1870mm
Max height bucket dump angle 63°
Min height 1300mm
Departure angle 22°
Ground clearance 157mm
Dumping distance 295mm
Track contact length 900mm
Dimensions
Overall dimensions 2169*1120*1300mm
Length including bucket 2169mm
Length excluding bucket 1850mm
Track contact length 180*72*35
Engine
Brand Lithium electricity/KOOP/Rato/B&S
Model Lithium iron phosphate/292f/R740/Vanguard23
Rated power 8kw,72V,200ah/15/16.8/17kw
Cylinder 2
Intake method Natural inhalation
Emission standard EPA/ERUO5
Fuel tank capacity 10L
